3 Piece Cast Iron Ball Valve

Description

3 Piece Cast Iron Ball Valve

1.Body: Cast Iron, WCB, CF8, CF8M

2. Cap: Cast Iron, WCB, CF8, CF8M

3. Ball: CF8, CF8M, Carbon Steel, Cast Iron

4. Stem: Stainless Steel

5. Gland Nut: AISI 304

6. Seat: PTFE, RTFE

7. Seal: PTFE

8. Packing: PTFE

9. Thurst Washer: PTFE

10. Spring Washer: AISI 304

11. Stem Nut: AISI 304

12. Bolt: AISI 304

13. Nut: AISI 304

14. Spring Washer: AISI 304

15. Handle: Stainless Steel

16. Locking Device: Stainless Steel

17. Handle Sleeve: PVC

Nominal Size: DN15 to DN100

Nominal Pressure: Class150

Full port or Reduced Port

Working Temperature : -20°C to 200°C (-4°F to 392°F)

Investment casting

Blow-out proof stem

Anti-static device (option)

Locking device

Flange dimension : DIN 2501 – PN40

Face to face: DIN 3202 – F1

Dimensions

DN	L	D	D1	D2	b	f	H	W	n-d0
15	130	95	65	45	14	2	75	130	4-14
20	150	105	75	55	16	2	90	140	4-14
25	160	115	85	65	16	2	95	140	4-14
32	180	135	100	78	18	3	110	170	4-18
40	180	135	100	78	18	3	130	200	4-18
50	230	160	125	100	20	3	140	220	4-18
65	290	180	145	120	22	3	170	350	8-18
80	310	195	160	135	24	3	180	350	8-18
100	350	230	190	160	24	3	250	550	8-22
